Vectors: Both the sampled
dots and the connecting
line are displayed.

Steps

From the Display menu press Type and select
the display mode.

Type

Vectors, Dots

Type

Menu

Set the Level of Persistence

Background

The Persistence function allows the GDS-
200/GDS-300 to mimic the trace of a traditional
analog oscilloscope. A waveform trace can be
configured to “persist” for a designated amount
of time.

Steps

From the Display menu press Persistence and
set the level of persistence with the slider or the
preset keys.

Persistence

Off, Short, Medium, Long,
Infinite

Persistence

Menu
