GDS-200 & GDS-300 Series User Manual
34
Setting the Language
Background The GDS-200/300 menu system can be set to
display a number of languages.
1. Access the Menu tray by tapping the title bar.
2. Press Utility>System>Language.
The Language menu will appear.
3. To set the language, press your preferred
language.
Switching Horizontal and Vertical View
Background By default the GDS-200/300 is set to the
vertical view.
Switch View 1. Tap the title bar to access the Menu tray.
2. Press the icon to toggle between horizontal
and vertical view.
Compensating a Probe
Background To demonstrate connecting the probes, we will
use the 1kHz calibration signal on the interface
panel and compensate the probe from this
signal.
Connection 1. Connect a probe to the CH1 BNC terminals.
