background image

GDS-200 & GDS-300 Series User Manual

178

3 or 4 Digit SMD Resistor Standards

For 3 or 4 digit SMD codes, the first 2 or 3 digits represent the base
value and the last digit represents the multiplier. The letter R is
used as a decimal point.
Example1: The code 220 equals 22Ω.
Example2: The code 12R0 equals 12.0Ω.

EIA-96 Code

The EIA-96 standard is a 3 letter code. The first 2 digits codify a
base value and the last digit is a letter that codifies a multiplier.
EIA-96 code is used for tolerances of 1%.

First Two Digits

Code Value Code Value Code Value Code Value Code Value Code Value

01

100 17

147 33

215 49

316 65

464 81

681

02

102 18

150 34

221 50

324 66

475 82

698

03

105 19

154 35

226 51

332 67

487 83

715

04

107 20

158 36

232 52

340 68

499 84

732

05

110 21

162 37

237 53

348 69

511 85

750

06

113 22

165 38

243 54

357 70

523 86

768

07

115 23

169 39

249 55

365 71

536 87

787

08

118 24

174 40

255 56

374 72

549 88

806

09

121 25

178 41

261 57

383 73

562 89

825

10

124 26

182 42

267 58

392 74

576 90

845

11

127 27

187 43

274 59

402 75

590 91

866

12

130 28

191 44

280 60

412 76

604 92

887

13

133 29

196 45

287 61

422 77

619 93

909

14

137 30

200 46

294 62

432 78

634 94

931

15

140 31

205 47

301 63

442 79

649 95

953

16

143 32

210 48

309 64

453 80

665 96

976
