OPERATION

47

Common Menu UI Elements

This section will give a brief overview of some of the common UI
elements that are used to select parameters and values in menus.
Not all of the UI elements look the same but will have similar
functions. User interface elements that are not shown below will be
specifically shown in the user manual.

Radio Check Boxes

Background

A radio checkbox allows a single option to be
selected.

Example

Selected in

checkbox

Toggle Switches

Background

Toggle switches are used to turn options on or off.

Example

Off position

On position

Sliding Scales

Background

Sliders are used to quickly enter a value, on a
sliding scale. They are usually accompanied by
some common preset value buttons.
