IB-23C650
SETUP
Table 8. Set-Point Setup Menu
Step Step Description
Top
Display
5.2 Local Set-Point 4 Fixed.
UP or DN selects YES or NO.
SCRL to advance to Step 5.3.
SETPT 4
5.3 Local Set-Point 4 High Limit.
UP or DN sets value.
SCRL to advance to Step 5.4.
SETPT 4
5.4 Local Set-Point 4 Low Limit.
UP or DN sets value.
SCRL to advance to Step 5.5.
SETPT 4
5.5 Local Set-Point 4 Initial Value.
UP or DN sets value.
SCRL to advance to Step 6.
SETPT 4
6 Power-up Set-Point Source.
UP or DN selects LAST or FIXED.
SCRL to advance to:
Step 7 from LAST, from REM SETP when input
2 is enabled, or from LOC SETP or SETPT 2
- 4 when chosen local set-point is ‘fixed,’ or
Step 6.1 from REM SETP when input 2 is not
enabled or option board not installed, or
Step 6.2 from LOC SETP or from SETPT 1 - 4
when the chosen local set-point is not ‘fixed’.
POWER UP
90
