IB-23C650
SETUP
Table 3. Digital Input Setup Menu
Middle
Display
Bottom
Display
Entry Description
ALLOWED NO
YES
= Allows digital input to switch control mode
only on closed transition (auto to manual)
= Allows digital input to switch control mode
from manual to auto, or auto to manual
DI1 FUNC RUN/STOP
RUN/HOLD
RUN/SKIP
= If DI closed: start profile at step 1
If DI open: reset and stop on step 1
= If DI closed: continue from current step
If DI open: stop and hold current step
= If DI closed: continue profile
If DI open: skip current step, continue
LOCKOUT YES
NO
= Locks out the front panel ramp/soak
commands indicated
R/H,RSET = Run/hold, reset commands
locked if run/stop selected
RUN/HOLD = Run/hold commands locked if
run/hold selected
SKIP = Skip commands locked if
run/skip selected
= Allows all front panel commands to the
ramp/soak algorithm
Also see note in 2.1.2 above.
DI1 FUNC RUN/STOP
RUN/RSET
RUN/HOLD
= If DI closed: start counting at preset value
If DI open: reset and stop at preset value
= If DI closed: continue from current count
If DI open: reset and begin counting from
preset value
= If DI closed: continue from current count
If DI open: stop and hold current count
63
