Micromod MOD: Modcell 2050R Users Guide User Manual
Page 166
IB-23C650
TUNING
Table 13. Autotune Procedure
Step
Step Description
Top
Display
4
Autotune Activation.
UP
enters autotune setup.
SCRL
to return to Step 2.
TAG NAME
5
Output Step Size.
UP
or
DN
adjusts output step size.
SCRL
to Step 6.
TAG NAME
6
Hysteresis Value.
UP
or
DN
adjusts hysteresis value.
SCRL
to Step 7.
TAG NAME
160
