IB-23C650
SETUP
Table 1. Base Configuration
Step Step Description
Top
Display
1 Base Configuration Menu.
UP moves to DISPLAYS **MENU**.
DN moves to INPUTS **MENU**.
SCRL advances to Step 2 (read only in auto).
BASE CFG
2 Main Power Frequency.
UP or DN selects 50 or 60 HERTZ.
SCRL advances to Step 3.
MAIN PWR
3 Process Input Type.
UP or DN selects process input type.
SCRL advances to:
Step 3.1 if input type is THERMCPL,
Step 3.2 if input type is RTD,
Step 4 if Input 2 is present, or
Step 5 (Output type) otherwise.
PROC INP
3.1 Process Input Thermocouple Type.
UP or DN selects thermocouple type.
SCRL advances to Step 3.2.
PROC INP
3.2 Process Temperature Calibration.
UP moves to Step 3.2.1.
SCRL advances to:
Step 4 if Input 2 is present, or
Step 5 (Output type) otherwise.
PROCESS
3.2.1 Process Calibration Correction.
UP or DN sets correction temperature.
SCRL advances to:
Step 4 if Input 2 is present, or
Step 5 (Output type) otherwise.
PR TEMP=
30
