IB-23C650
SETUP
Table 3. Digital Input Setup Menu
Middle
Display
Bottom
Display
Entry Description
**MENU** None.
INPUT 1 None.
FUNCTION NONE
AUTO/MAN
ALRM ACK
TOTALIZE
RAMPSOAK
SETP SEL
OUTP TRK
= Not used
= Switch control mode
= Global alarm acknowledge
= Issue command(s) to totalizer algorithm
= Issue command(s) to ramp/soak algorithm
= Select active set-point
= Cause output to track input 2 (only available
when input 2 is electrical and output is
current proportioning)
OUT ENAB NO
YES
= Leave output at current value when
switching control mode to manual with
digital input
= Set output to value below when switching
control mode to manual with digital input
OUT VAL xx.x x to xxx%
Limited by output mA high and low limits
above. Output generated when switching to
manual with digital input.
LOCKOUT YES
NO
= Lockout front panel changes from auto to
manual control mode
= Allow front panel changes from auto to
manual control mode
Note: NO allows changes from front panel,
which may conflict with digital input state.
Digital input actions take place only at
‘transitions’ so that a subsequent front panel
override can take place if allowed.
61
