SETUP
Table 2. Input Setup Menu
Middle
Display
Bottom
Display
Entry Description
OPTION MANUAL
LAST
= Makes instrument return to the manual
mode after the input failure is corrected.
= Makes instrument return to the mode it was
in when the input failure occurred.
SETUP If input 2 is being used as a remote bias or
ratio value input, the value will be displayed as
follows: xxx.xx.
UNITS CELSIUS
FAHRENHT
= Celsius
= Fahrenheit
MA. HI or
MV. HI or
VOLTS HI
or
POSITION
xx.xx
xx.x
x.xx
x.xxx
1.00 to 54.00 mA dc
–8.0 to 120 mV dc
0.1 to 6.00 V dc
0.100 to 1.000 (wiper position)
MA. LO or
MV. LO or
VOLTS LO
or
POSITION
xx.xx
xx.x
x.xx
x.xxx
0.00 to 53.00 mA dc (minimum span = 1.00)
–10.0 to 118 mV dc (minimum span = 2.0)
0.00 to 5.90 V dc (minimum span = .10)
0.000 to 0.900 (wiper position)
(minimum span = .100)
LIN TYPE NONE
SQR ROOT
When SQR ROOT linearization is selected, the
engineering units low value defaults to zero and
will not appear in this menu.
