Micromod MOD: Modcell 2050R Users Guide User Manual
Page 130
IB-23C650
INTRODUCTION
124
Alarm Light
Alarm Scroll
Key
Loop Tag
Display
Tag Key
Process
Variable
Display
Manual Key
Auto Key
Status
Displays
Remote/Local
Key
Scroll Key
Up Key
Down Key
Lower
Engineering
Display
Process
Set-Point Output
Variable
Variable Bar graph
Bar Graph
Bar Graph
Figure 15. Instrument Front Panel
