IB-23C650
CALIBRATION DATA
Table 15. Main/Option Board Calibration (Base Configuration Menu)
Step Step Description
Top
Display
17 Option Board Calibration. Constants
UP begins calibration at Step 17.1.
SCRL advances to step 18, Default Database
entry point, in BASE CFG MENU (Table 1).
OPTN BRD
17.1 Input 2 Voltage Ref. High
UP begins entry at most significant digit. Use UP
or DN to set the digit, then SCRL to scroll to the
next digit. Repeat for all digits.
SCRL advances to:
Step 17.1.1 if value was changed.
Step 17.2 otherwise.
INPUT 2
17.1.1 Are You Sure You Want to Change Input 2 Vref
Hi?
UP selects YES or DN selects NO.
SCRL advances to:
Step 17.1 on NO.
Step 17.2 on YES.
ARE YOU
17.2 Input 2 Voltage Ref. Lo
UP begins entry at most significant digit. Use UP
or DN to set the digit, then SCRL to scroll to the
next digit. Repeat for all digits.
SCRL advances to:
Step 17.2.1 if value was changed.
Step 17.3. otherwise.
INPUT 2
17.2.1 Are You Sure You Want to Change Input 2 Vref
Lo?
UP selects YES or DN selects NO.
SCRL advances to:
Step 17.2 on NO.
Step 17.3 on YES.
ARE YOU
210
