Table 12. Tune Menu
Step Step Description
Top
Display
13 Position Proportioning Deadband.
UP or DN sets value.
SCRL to advance to Step 14.
POS PROP
14 Position Proportioning Preact.
UP or DN sets value.
SCRL to return to Step 1.
POS PROP
15 Time Proportioning Cycle Time.
UP or DN sets value.
SCRL to return to Step 1.
CYCLE
16 Heat/Cool Output Crossover.
UP or DN sets value.
SCRL to advance to Step 17.
CROSSOVR
17 Crossover Transition Band Width.
UP or DN sets value.
SCRL to advance to Step 18.
CROSSOVR
18 Crossover Output Off Hysteresis.
UP or DN sets value.
SCRL to advance to:
Step 19 if output type is HC/RR, or
Step 20 output type is HC/CR, or
Step 1 otherwise.
OUTPUT
19 Heat Cycle Time.
UP or DN sets value.
SCRL to advance to Step 20.
HEAT
20 Cool Cycle Time.
UP or DN sets value.
SCRL to return to Step 1.
COOL
