Calibration data – Micromod MOD: Modcell 2050R Users Guide User Manual
Page 211
IB-23C650
CALIBRATION DATA
CALIBRATION DATA
INTRODUCTION
The 2050R base controller (main board) is factory calibrated and does not
require calibration data. The main board calibration data procedure is for
factory use only and is included for reference only.
Option board calibration data is entered after installing the option board.
Follow the steps in the BASE CFG MENU to get to the OPTN BRD CALIBRAT
entry point. (You must have a non-zero configuration password to get this
field.). Enter the calibration data supplied with the option board as instructed
in Table 15.
205
