Table 10. Integrator/Totalizer Menu
Middle
Display
Bottom
Display
Entry Description
**MENU** None.
PRED CNT NO
YES
= Counts until turned off or until maximum
count (9,999,999) is reached. At maximum
count, totalizer will hold until operator resets.
= Counts until predetermined count is
reached, then resets to preset value and
starts counting again.
THRSHOLD xxxx 0 to ‘Engineering Units High Value’ in
engineering units for electrical inputs.
Temperature inputs can be set from
engineering low to high value.
Totalizer will not count signals below threshold
value.
IS OFF
or
IS ON
Note: If SCRL is pressed when totalizer is on,
message ‘TOTALIZE RD ONLY’ is displayed
for one second, to indicate totalizer is on and
setup therefore is read only. To make change
to the setup, turn off totalizer in Displays Menu.
Any change to setup will cause profile to reset.
If no change is made, totalizer can be turned
back on in Displays Menu, and will continue
from stopping point.
DIRECT UP
DOWN
= Totalizer counts up from preset value.
= Totalizer counts down from preset value.
RATE PER SEC
or
PER MIN
or
PER HOUR
Example: If input is 100 engineering units, time
base is PER SEC, and scale factor (Step 8) is
1.0, totalized count will increase at rate of 100
counts per sec. If scale factor is 2.0, totalized
count will increase at rate of 50 counts per sec.
See Table 13 for more examples.
105
