IB-23C650
SETUP
Table 2. Input Setup Menu
Middle
Display
Bottom
Display
Entry Description
**MENU** None.
POINT 0.
0.0
0.00
0.000
= Display units
= Display tenths
= Display hundredths (electrical inputs only)
= Display thousandths (electrical inputs only)
Positioning of the decimal point in this menu
sets the decimal location for ‘engineering unit’
entries in all menus. If values have already
been set up, they may have to be changed
depending on decimal positioning in this menu.
SETUP None.
UNITS CELSIUS
FAHRENHT
= Celsius
= Fahrenheit
MA. HI or
MV. HI or
VOLTS HI
or
POSITION
xx.xx
xx.x
x.xx
x.xxx
1.00 to 54.00 mA dc
–8.0 to 120 mV dc
0.10 to 6.00 V dc
0.100 to 1.000 (wiper position relative to the
high and low ends of the element)
MA. LO or
MV. LO or
VOLTS LO
or
POSITION
xx.xx
xx.x
x.xx
x.xxx
0.00 to 53.00 mA dc (minimum span = 1.00)
-10.0 to 118 mV dc (minimum span = 2.0)
0.00 to 5.90 V dc (minimum span = .10)
0.000 to 0.900 (wiper position)
(minimum span = .100)
NOTE: input low must be less than input high.
47
