Micromod MOD: Modcell 2050R Users Guide User Manual
Page 105
IB-23C650
SETUP
Table 9. Ramp/Soak Profile Setup Menu
Middle
Display
Bottom
Display
Entry Description
RELAY A
ON
OFF
State of the relay during segment.
RELAY B
ON
OFF
State of the relay during segment.
RELAY C
ON
OFF
State of the relay during segment.
GUARANTD
NO
YES
=
= Time is counted only if process variable is
within hysteresis deadband set above (Step 3
or 4)
SETUP
None.
START SP
xxxx
Between ‘Local Set-point Low Limit’ and ‘Local
Set-point High Limit’
•
•
•
•
•
•
•
•
•
SETUP
None.
START SP
xxxx
Between ‘Local Set-point Low Limit’ and ‘Local
Set-point High Limit’
99
