Micromod MOD: Modcell 2050R Users Guide User Manual
Page 90
IB-23C650
SETUP
Table 7. Auto/Manual Ratio Bias Setup Menu
Step
Step Description
Top
Display
7
Ratio Source for Ratio and Bias Type.
UP
or
DN
selects source.
SCRL
to advance to:
Step 8 from LOCAL, or
Step 9 from REMOTE.
RATIO
8
Bias Source for Ratio and Bias Type.
UP
or
DN
selects source.
SCRL
to advance to Step 9.
BIAS
9
Ratio Balance for Ratio and Bias Type.
UP
or
DN
selects type.
SCRL
to advance to:
Step 10 from STANDARD, or
Step 1 from AUTO.
RATIO
10
Bias Balance for Ratio and Bias Type.
UP
or
DN
selects type.
SCRL
to return to Step 1.
BIAS
84
