IB-23C650
SETUP
Table 2. Input Setup Menu
Middle
Display
Bottom
Display
Entry Description
ACTION
NONE
LOCAL
NONE
HOLD POS
CLSD POS
OPEN POS
Output type is NOT Position Proportioning:
= No action taken on input 2 failure.
= On input 2 failure, make the setpoint mode
(or amrb ratio or bias source) local, and set
it to the fault value below.
Output type is Position Proportioning:
= No action taken on input 2 failure.
= On input 2 failure, hold the current valve
position.
= On input 2 failure, drive the valve closed.
= On input 2 failure, drive the valve open.
NOTE: On input 2 failure, control mode is set
to manual and output to Process Fault Output.
If recovery option is LAST and controller was in
auto, it will return to auto when the fault clears.
VALUE xxxx –3000 to 30000
This value is limited by local set-point or
ratio/bias limits. This is the value which the
local set-point takes at a fault condition.
LEVL PCT xx 0 to 100%
See entry description with Step 3.8.
57
