Micromod MOD: Modcell 2050R Users Guide User Manual
Page 62
IB-23C650
SETUP
Table 2. Input Setup Menu
Step
Step Description
Top
Display
4.7
Input 2 Fault Action.
UP
or
DN
selects action.
SCRL
to advance to:
Step 4.8 for LOCAL, or
Step 4.9 otherwise.
I2 FAULT
4.8
Input 2 Fault Value.
UP
or
DN
sets value.
SCRL
to advance to Step 4.9.
I2 FAULT
4.9
Input 2 Fault Detection Level Percentage.
UP
or
DN
sets percent.
SCRL
to advance to Step 5.
I2 FAULT
56
