Micromod MOD: Modcell 2050R Users Guide User Manual
Page 118
IB-23C650
SETUP
Table 11. Alarm Settings Menu
Step
Step Description
Top
Display
7.1.3
Alarm 1 Priority.
UP
or
DN
selects 1 or 2.
SCRL
to advance to Step 7.1.4.
ALARM 1
7.1.4
Alarm 1 Hysteresis.
UP
or
DN
sets value.
SCRL
to advance to Step 8.
ALARM 1
8
Alarm 2 Setup.
UP
begins setup at Step 8.1.
SCRL
to advance to Step 9.
ALARM 2
8.1
Alarm 2 Type.
UP
or
DN
selects type.
SCRL
to advance to:
Step 8 if type is NONE, or
Step 8.1.1 if output type is heat/cool, or
Step 8.1.2 otherwise.
ALARM 2
8.1.1
Alarm 2 Trip-Point in Heating Band.
UP
or
DN
selects YES or NO.
SCRL
to advance to Step 8.1.2.
AL2 TRIP
•
•
•
•
•
•
•
•
•
10.1.4
Alarm 4 Hysteresis.
UP
or
DN
sets value.
SCRL
to return to Step 1.
ALARM 4
112
