Micromod MOD: Modcell 2050R Users Guide User Manual
Page 50
IB-23C650
SETUP
Table 1. Base Configuration
Step
Step Description
Top
Display
18.2
Configuration has Changed.
SCRL
advances to Step 19.
CONFIG
19
Lock configuration menus
UP
or
DN
selects YES or NO
SCRL
advances to Step 20.
LOCK CFG
20
Software Revision Number.
SCRL
advances to Step 21.
SOFTWARE
21
Display Revision Number.
SCRL
advances to Step 1.
DISPLAY
44
