IB-23C650
SETUP
Table 12. Tune Menu
Step Step Description
Top
Display
1 Tune Menu.
UP moves to ALARMS **MENU**.
DN moves to DISPLAYS **MENU**.
SCRL to begin setup at Step 2.
TUNE
2 Tag Name.
UP begins tag entry. First tag character will flash.
Then UP or DN sets character (Selecting UP first
begins selections at ’A’; selecting DN first
begins selection at ’9‘.)
SCRL to next character.
Repeat for all characters, SCRL to beginning.
UP repeats tag entry, or
SCRL to advance to:
Step 12 if A/M ratio bias is enabled and type is
BIAS, or
Step 11 if A/M ratio bias is enabled and type
is any other, or
Step 3 if A/M ratio bias is not enabled and
output type is ON/OFF, or
Step 4 if A/M ratio bias is not enabled and
output type is HEAT/COOL, or
Step 6 if A/M ratio bias is not enabled and
output type is any other.
TAG
3 On/Off Differential Gap.
UP or DN sets value.
SCRL to advance to:
Step 9 if remote set-point is enabled, or
Step 14 otherwise.
ON/OFF
4 Gain, Heat.
UP or DN sets value.
SCRL to advance to Step 5.
GAIN
5 Gain, Cool.
UP or DN sets value.
SCRL to advance to Step 7.
GAIN
6 Gain (proportional response).
UP or DN sets value.
SCRL to advance to Step 7.
114
