IB-23C650
SETUP
Table 1. Base Configuration
Step Step Description
Top
Display
3.2.1
(cont’d) Process Calibration Correction.
4 Input 2 Enable. (Requires Option Board)
UP selects YES or DN selects NO.
SCRL advances to:
Step 4.1 (Input 2 Type) from YES, or
Step 5 (Output type) from NO.
INPUT 2
4.1 Input 2 Type.
UP or DN selects input 2 type.
SCRL advances to:
Step 4.1.1 if input type is THERMCPL,
Step 4.1.2 if input type is RTD, or
Step 5 (Output type) otherwise.
INPUT 2
4.1.1 Input 2 Thermocouple Type.
UP or DN selects thermocouple type.
SCRL advances to Step 4.1.2.
INPUT 2
4.1.2 Input 2 Temperature Calibration.
UP moves to Step 4.1.2.1.
SCRL advances to Step 5.
INPUT 2
32
