IB-23C650
SETUP
Table 11. Alarm Settings Menu
Middle
Display
Bottom
Display
Entry Description
**MENU** None.
OCCUR OF NONE
DG
P1
DG, P1
P2
DG, P2
P1, P2
DG,P1,P2
= Beeper never sounds for an alarm condition
Beeper sounds on:
= diagnostic alarm
= priority 1 process alarm
= diagnostic or priority 1 process alarm
= priority 2 process alarm
= diagnostic or priority 2 process alarm
= priority 1 or 2 process alarm
= diagnostic, or priority 1 or 2 process alarm
REQD ON NONE
DG
P1
DG, P1
P2
DG, P2
P1, P2
DG,P1,P2
= No alarm acknowledgment required for any
alarm condition
Alarm acknowledgement required for:
= diagnostic alarm
= priority 1 process alarm
= diagnostic or priority 1 process alarm
= priority 2 process alarm
= diagnostic or priority 2 process alarm
= priority 1 or 2 process alarm
= diagnostic, or priority 1 or 2 process alarm
DIAG ON YES
NO
= Report the overconfigured condition.
= Don’t report the overconfigured condition.
Time related items such as ramp soak, totalized
count, and integral and derivative responses will
be in error in this condition. The diagnostic
should only be turned off if it is both necessary
and acceptable to run in the overconfigured
condition.
109
