IB-23C650
SETUP
Table 12. Tune Menu
Step Step Description
Top
Display
8
(cont’d) Preact Value.
Step 13 if A/M ratio bias is not enabled and
output type is POS PROP, or
Step 15 if A/M ratio bias is not enabled and
output type is TIM PROP or ON/OFF, or
Step 16 if A/M ratio bias is not enabled and
output type is HEAT/COOL, or
Step 1 otherwise.
9 Remote Set-Point Ratio. (requires option board)
UP or DN sets value.
SCRL to advance to Step 10.
REM SETP
10 Remote Set-Point Bias. (requires option board)
UP or DN sets value.
SCRL to advance to:
Step 13 if output type is POS PROP, or
Step 15 if output type is TIM PROP or ON/OFF,
or
Step 16 if output type is HEAT/COOL, or
Step 1 otherwise.
REM SETP
11 Auto/Manual Ratio Bias, Ratio.
UP or DN sets value.
SCRL to advance to:
Step 12 if type is BIAS or RATIO AND BIAS, or
Step 13 if output type is POS PROP, or
Step 15 if output type is TIM PROP or ON/OFF,
or
Step 16 if output type is HEAT/COOL, or
Step 1 otherwise.
A/M R-B
12 Auto/Manual Ratio Bias, Bias.
UP or DN sets value.
SCRL to advance to:
Step 13 if output type is POS PROP, or
Step 15 if output type is TIM PROP or ON/OFF,
or
Step 16 if output type is HEAT/COOL, or
Step 1 otherwise.
A/M R-B
118
