IB-23C650
SETUP
Table 2. Input Setup Menu
Step Step Description
Top
Display
3.10 Recovery Option.
UP or DN selects option.
SCRL to advance to:
Step 4 if input 2 is enabled, or
Step 5 otherwise.
RECOVERY
4 Input 2 Setup. (Requires Option Board)
UP begins setup at:
Step 4.7 if output type is POS PROP, or
Step 4.1 if input 2 type is thermocouple or
RTD, or
Step 4.2 if input type 2 is mA, mV, V, or
slidewire
SCRL to advance to Step 5.
INPUT 2
4.1 Input 2 Temperature Units.
UP or DN selects units.
SCRL to advance to Step 4.5.
IN2 TEMP
4.2 Input 2 High Value.
UP or DN sets high value of input 2.
SCRL to advance to Step 4.3.
INPUT 2
INPUT 2
INPUT 2
INP2 HI
4.3 Input 2 Low Value.
UP or DN sets low value of input 2.
SCRL to advance to Step 4.7 if either digital input
function is OUTP TRK, go to Step 4.4 otherwise.
INPUT 2
INPUT 2
INPUT 2
INP2 LO
4.4 Input 2 Linearization Type.
UP or DN selects type.
SCRL to advance to Step 4.5.
INPUT 2
52
