Micromod MOD: Modcell 2050R Users Guide User Manual
Page 68
IB-23C650
SETUP
Table 3. Digital Input Setup Menu
Step
Step Description
Top
Display
2.1.3
Manual to Auto Transition Allowed.
UP
or
DN
selects YES or NO.
SCRL
to advance to Step 2.1.10.
MAN-AUTO
2.1.4
Ramp/Soak Digital Input 1 Function.
UP
or
DN
selects function.
SCRL
to advance to Step 2.1.5.
RAMPSOAK
2.1.5
Ramp/Soak Command Lockout.
UP
or
DN
selects YES or NO.
SCRL
to advance to Step 2.1.10.
R/H,RSET
or
RUN/HOLD
or
SKIP
2.1.6
Totalizer Digital Input 1 Function.
UP
or
DN
selects function.
SCRL
to advance to Step 2.1.7.
TOTALIZE
62
