IB-23C650
INTRODUCTION
Ranging of the RTD and Thermocouple is automatic. The process input is
isolated from the rest of the instrument. A 24V dc transmitter power supply is
provided for use with a two-wire mA dc input on both process and remote set-
point inputs.
When the controller is equipped with an option card, RS-485 communication
capability is provided via either a 2-wire or 4-wire bus. This feature supports
communication with a host device such as a personal computer or MODCELL
Multiloop Processor using the Extended Modbus Protocol. All information
pertaining to Modbus communication is provided in the MODBUS
Communications Supplement IB-23C650M.
IDENTIFICATION INFORMATION
BASE NUMBER 2050R MODCELL 2050 Single Loop Controller
2051R MODCELL 2051R Single Loop Controller
for Replacement of Foxboro 62H and
SPEC 200
INSTRUMENT POWER Z 85-250 V ac, 47-440 Hz
A 20-50 V dc, 20-35 V ac
ELECTRICAL CODE 23 FM Approved Class 1, Division 2, Groups
A, B, C, D and CSA Certified Class 1,
Division 2, Groups A, B, C, D and UL Listed
(Non-Hazardous Location)
12 General Purpose, EU EMC Compliant
(see notes on pages 10 and 20).
OPTIONS 0 None
1 2nd Isolated universal analog input, 2nd
non-isolated analog output, and RS-485
Communications Hardware
FIRMWARE VERSION 02 Version 2
MODEL A 1 st design level
B 2 nd design level (EU EMC Compliant)
Sample Number: 2050RZ23102B
See the product Data Plate as shown on the next page for specific
identification of your controller.
2
