IB-23C650
SETUP
Table 10. Integrator/Totalizer Menu
Middle
Display
Bottom
Display
Entry Description
DEC PT
0.
0.0
0.00
0.000
Sets decimal location for scale factor in Step 8.
= 1 to 30000
= .1 to 3000.0
= .01 to 300.00
= .001 to 30.000
FACTOR xxxx 0.001 to 30000 (Set decimal point in Step 7).
See also flow rate time base (Step 6), and the
Totalizer Operation section.
VALUE xxxxxxx .000 to 9999999 (7 significant digits, with
decimal point placed per Inputs)
Value at which totalizer starts counting at
startup or reset.
COUNT xxxxxxx .000 to 9999999 (7 significant digits, with
decimal point placed per Inputs)
Value at which totalizer resets when wrap
function is enabled. If totalizer event relay
enabled in Alarms, relay transfers to signal that
predetermined count has been reached.
107
