IB-23C650
CALIBRATION DATA
Table 15. Main/Option Board Calibration (Base Configuration Menu)
Middle
Display
Bottom
Display
Entry Description
CALIBRAT NOTE: These calibration values should be
altered only when installing the option board for
the first time. Changing any or all of the 4
calibration values will cause the instrument to
mark the option board calibration valid.
Calibration data is shipped with the option
board.
VREF HI xxxxxxxx = Any hexadecimal digit.
See note on Step 17.
SURE? YES
NO
This step is present only to guard against
accidentally changing this critical calibration
value.
VREF LO xxxxxxxx = any hexadecimal number.
See note on Step 17.
SURE? YES
NO
This step is present only to guard against
accidentally changing this critical calibration
value.
211
