Tbl9 - ramp/soak – Micromod MOD: Modcell 2050R Users Guide User Manual
Page 100
IB-23C650
SETUP
Table 9. Ramp/Soak Profile Setup Menu
Step
Step Description
Top
Display
1
Ramp/Soak Menu.
UP
moves to SETPTS **MENU**.
DN
moves to TOTALIZE **MENU** if
integrator/totalizer is enabled, or to ALARMS
**MENU** otherwise.
SCRL
to begin setup at Step 2.
RAMPSOAK
2
Ramp/Soak Repeat.
UP
selects YES or
DN
selects NO.
SCRL
to advance to Step 3.
RAMPSOAK
3
Soak Hysteresis.
UP
or
DN
sets value.
SCRL
to advance to Step 4.
SOAK
4
Ramp Hysteresis.
UP
or
DN
sets value.
SCRL
to advance to Step 5.
RAMP
5
Ramp/Soak Status.
SCRL
to advance to Step 6.
RAMPSOAK
6
Ramp/Soak Time Units.
UP
or
DN
sets units.
SCRL
to advance to Step 7.
RAMPSOAK
7
Ramp/Soak Segments.
UP
or
DN
sets value.
SCRL
to advance to:
Step 8 if number of segments is 0, or
Step 7.1 otherwise.
RAMPSOAK
7.1
Ramp/Soak Segment 1 Setup.
UP
begins segment 1 setup at Step 7.1.1.
SCRL
to advance to Step 7.2.
SEG 1
