IB-23C650
SETUP
Table 11. Alarm Settings Menu
Step Step Description
Top
Display
5 Priority 1 Relay Action.
UP or DN selects action.
SCRL to advance to:
Step 6 if acknowledge is required on priority 2
process alarms, or
Step 7 otherwise.
P1 RELAY
6 Priority 2 Relay Action.
UP or DN selects action.
SCRL to advance to Step 7.
P2 RELAY
7 Alarm 1 Setup.
UP begins setup at Step 7.1.
SCRL to advance to Step 8.
ALARM 1
7.1 Alarm 1 Type.
UP or DN selects type.
SCRL to advance to:
Step 8 if type is NONE, or
Step 7.1.1 if output type is heat/cool and output
High or low is selected, or
Step 7.1.2 otherwise.
ALARM 1
7.1.1 Alarm 1 Trip-Point in Heating Band.
UP or DN selects YES or NO.
SCRL to advance to Step 7.1.2.
AL1 TRIP
7.1.2 Alarm 1 Trip-Point.
UP or DN sets trip-point.
SCRL to advance to Step 7.1.3.
ALARM 1
110
