Micromod MOD: Modcell 2050R Users Guide - Manual (Page 222)

IB-23C650
Data Base Record
Top
Display
Middle
Display
Bot. Disp.
Entry
Top
Display
Middle
Display
Bot. Disp.
Entry
BASE CFG **MENU** * BRD CALIBRAT
MAIN PWR FREQ DEFAULT DATABASE
PROC INP TYPE LOCK CFG MENUS
PROC INP TC TYPE SOFTWARE VERSION
PROCESS TEMP CAL DISPLAY VERSION
PR TEMP= xxxx INPUTS **MENU**
INPUT 2 ENABLE DECIMAL POINT
INPUT 2 TYPE PROC INP SETUP
INPUT 2 TC TYPE PRC TEMP UNITS
INPUT 2 TEMP CAL PROC INP ***** HI
I2 TEMP= xxxx PROC INP ***** LO
OUTPUT TYPE PROCESS LIN TYPE
CONTROL ACTION PROC ENG UNITS HI
MA. OUTP ACTION PROC ENG UNITS LO
HEAT OUT ACTION PR FAULT OUTPUT
COOL OUT ACTION FIXED FAULT OP
VALVE CALIB PR FAULT LEVL PCT
CALIBRAT OPEN POS RECOVERY OPTION
CALIBRAT CLSD POS INPUT 2 SETUP
HOLD PWR UP MSG IN2 TEMP UNITS
POWER UP MODE INPUT 2 ***** HI
RAT BIAS ENABLE INPUT 2 ***** LO
AUTOTUNE ENABLE INPUT 2 LIN TYPE
RAMPSOAK ENABLE IN2 ENG UNITS HI
TOTALIZE ENABLE IN2 ENG UNITS LO
RS-485 ENABLE I2 FAULT ACTION
TUNE PASSWORD I2 FAULT VALUE
CONFIG PASSWORD I2 FAULT LEVL PCT
CHK SUM DATABASE ENG UNIT LABEL
