Page 110
IB-23C650
SETUP
Table 10. Integrator/Totalizer Menu
Step
Step Description
Top
Display
1
Totalizer Menu.
UP
moves to RAMPSOAK **MENU** if ramp/soak
is enabled, or to RAT BIAS **MENU** if ratio bias is
enabled, or to SETPTS **MENU** otherwise.
DN
moves to ALARMS **MENU**.
SCRL
to begin setup at Step 2.
TOTALIZE
2
Wrap at Predetermined Count.
UP
or
DN
selects YES or NO.
SCRL
to advance to Step 3.
WRAP AT
3
Set Threshold Value.
UP
or
DN
sets value.
SCRL
to advance to Step 4.
INPUT
4
Totalizer Status.
SCRL
to advance to Step 5.
TOTALIZE
5
Totalizer Direction.
UP
or
DN
selects UP or DOWN.
SCRL
to advance to Step 6.
TOTALIZE
6
Totalizer Flow Rate Time Base.
UP
or
DN
selects time base.
SCRL
to advance to Step 7.
TOTALIZE
104
