IB-23C650
BASIC OPERATION
2. Select whether to lock out the front panel from making set-point transfers,
whether transitions are allowed between local and remote set-points, and
the digital input action (DIRECT or REVERSE).
3. Choose which set-points to select between in the digital set-point
selection list (e.g., LOC, LO2). Refer to Table 3 for information on the DIG
INPT MENU.
4. Enable the digital input in the DISPLAYS MENU.
A transition in the digital input state (opened to closed, or closed to opened)
will now cause a set-point transfer. For example, if a digital input is set up for
set-point selection between LOC and LO2 (using DIRECT action), a state
change of the digital input from closed to opened will cause a transfer to LO2,
and a change from opened to closed will cause a set-point transfer to LOC.
Similarly, if the digital input is set up for set-point selection between a local
set-point and a remote set-point, changing the digital input state will cause a
set-point transfer between local and remote.
Example of Digital Input Action vs Set-point Source for
One Digital Input
Digital Input Action*
DI-1 or DI-2
DIRECT REVERSE
Set-Point Source
(LOC, LO2)
selected
SPT Source
(LO3, REM)
selected
SPT Source
closed open LOC LO3
open closed LO2 REM
To select the set-point using both digital inputs, complete the following steps:
1. In the DIG INPT MENU, enable “set-point select“ as the digital input
function for digital inputs.
2. Select whether or not to lock out the front panel from making set-point
transfers, whether transitions are allowed between local and remote set-
points, and the digital input action (DIRECT or REVERSE).
3. Choose which set-points to select between in the digital set-point
selection list (e.g., L1, 3, 4, R). Refer to Table 3 for information on the
DIG INPT MENU.
4. Enable the digital inputs in the DISPLAYS MENU.
145
