SETUP
Table 4. Milliamp Output Setup Menu
Middle
Display
Bottom
Display
Entry Description
**MENU** None.
MA. HIGH xx.x 01.0 to 54.0 mA dc
The current produced by 100% output from the
control algorithm.
( i. e. ,100% = 20 mA dc)
MA. LOW xx.x 0 to (mA high – 1) mA dc
The current produced by 0% output from the
control algorithm.
Example: 0% = 4 mA dc
HI LIMIT xx.x 0.1 to 110.0% of heat output span
The maximum value for heat output.
HI LIMIT xx.x 0.1 to 110.0% of cool output span
The maximum value for cool output.
HI LIMIT xx.x 10.0 to 110.0% of mA output span
10.0 to 100% of relay output span
(limited to 50 mA maximum)
LO LIMIT xx.x –8% to (high limit – 1.0)% of mA output span
0% to (high limit – 1.0)% of relay output span
(limited to 0 mA minimum)
MANUAL YES
NO
=Output HI and LO limits apply in manual or
output tracking.
= Output is not limited in manual or output
tracking.
OUTP SRC LAST
FIXED
= Power up with the same output value as at
power down
= Power up with fixed value below
73
