IB-23C650
SETUP
Table 8. Set-Point Setup Menu
Middle
Display
Bottom
Display
Entry Description
**MENU** None.
None.
FIXED NO
YES
= Allows changes in Displays menu
= This local set-point can be changed at the
Initial Value entry only, Step 2.4.
HI LIMIT xxxx Low limit to 30000
LO LIMIT xxxx –3000 to high limit
INIT VAL xxxx Low limit to high limit
The current value of this local setpoint.
None.
ENABLE NO
YES
= This set-point cannot be selected
= Set-point selectable from front panel and/or
digital input(s)
FIXED NO
YES
= Allows changes in Displays menu
= This local set-point can be changed at the
Initial Value entry only, Step 3.5.
HI LIMIT xxxx Low limit to 30000
87
