IB-23C650
SETUP
Table 11. Alarm Settings Menu
Step Step Description
Top
Display
1 Alarms Menu.
UP moves to TOTALIZE **MENU** if totalizer is
enabled, or to RAMPSOAK **MENU** if
ramp/soak is enabled, or to RAT BIAS
**MENU** if ratio bias is enabled, or to SETPTS
**MENU** otherwise.
DN moves to TUNE **MENU**.
SCRL to begin setup at Step 2.
ALARMS
2 Beep on Occurrence Of.
UP or DN selects type.
SCRL to advance to Step 3.
BEEP ON
3 Alarm Acknowledge Required.
UP selects YES or DN selects NO.
SCRL to advance to Step 4.
ALRM ACK
4 Overconfigured Diagnostic
UP selects YES or DN selects NO.
SCRL to advance to:
Step 5 if acknowledge is required on priority 1
process alarms, or
Step 6 if acknowledge is required on priority 2
process alarms, or
Step 7 otherwise.
OVERCFGD
108
