RFC 2544
86 AXS-200/850
Frame Loss Results
Frame Loss Results
Press , select RFC 2544, Results, and the Frame Loss tab.
³
Status: Displays the test status as
“--”, In Progress, Completed, or
Aborted. Once the Frame Loss test
is completed or stopped, the
Pass/Fail verdict is displayed,
when enabled.
³
Max. Rate: Displays the configured
value of maximum rate in Mbps or
%.
Note: Max. Rate will be displayed only when the Dual Test Set parameter is set
to Disabled in Global Configuration on page 58.
³
Duration: Displays the test duration in D HH:MM:SS format.
³
Threshold: The frame loss Pass/Fail threshold can be configured in
percentage at all times. When the value is changed, the verdict of the
subtest gets re-evaluated and updated.
Note: Threshold will not be displayed when the Dual Test Set parameter is set to
Local in Global Configuration on page 58.
