Traffic Generation & Monitoring
142 AXS-200/850
Stream Configuration
Stream Configuration
The stream configuration parameters define the Ethernet, UDP, and IP layer
header values for background streams.
Press , select Traffic Generation & Monitoring, Background Stream
Config, and the Stream tab.
Note: Only Background Stream and Destination MAC Address is configurable,
if Ethernet framing is selected in Global Configuration.
³
Background Stream: Select any
of the three background streams
for which the stream parameters
are to be configured.
³
Destination MAC Address: Enter
the MAC address if the Resolve
MAC Address is disabled. The
MAC address range is from
00:00:00:00:00:00 to
FF:FF:FF:FF:FF:FF. The default
value is FE:FE:FE:FE:FE:FE.
When the Destination MAC
Address field is selected for
editing, the Latest MAC’s button
appears on the bottom left corner
of the screen. Press the
corresponding function key to
display the list of previously
configured MAC addresses. Select
the desired MAC address from the
list, if any.
