Tools
186 AXS-200/850
Ping Configuration
Ping Configuration
The Ping tool is used to determine if a network device is reachable.
Press , select Tools, Ping, and the Configuration tab.
³
IP Address: Enter the IP address of
the network device to be detected.
The default setting for IPv4 is
10.10.0.0 or is set automatically to
the IP address of the target module
from the Remote Loopback mode.
The destination IP address is
configured only when
Ethernet/IPv4/UDP is selected.
The default setting for IPv6 is
2001:0000:0000:0000:0000:0000:0000:0000 or is set automatically to
the IP address of the target module from the Remote Loopback mode.
The destination IP address is configured only when Ethernet/IPv6/UDP
is selected.
The accepted range for IPv4 is 0.0.0.0 to 255.255.255.255. The default
value is 0.0.0.0.
The IPv6 Address can either be the Link-Local IPv6 Address or the
Global IPv6 Address.
The acceptable range for IPv6 is from
000:0000:0000:0000:0000:0000:0000:0001 to
FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF.
