RFC 2544
Ethernet Test Set 75
Summary Results
Summary Results
When the RFC 2544 test is run, a summary of the results as well as the
detailed results per subtest is collected. The Summary results page
displays the progress of each subtest. The progress per subtest is
monitored and updated on a per second basis. Once the subtest is
completed, its Pass/Fail result is displayed. The top half of the Summary
results page is static and is common for all subtests, however the bottom
half is dynamic and changes with each subtest.
Press , select RFC 2544, Results, and the Summary tab.
The progress Status of each subtest is
indicated as follows:
³
“--” (test has not started)
³
In Progress
³
Completed
³
Aborted
³
Aborted – No remote
connection
Note: When the Dual Test Set parameter is set to Remote in Global Configuration
on page 58, only Start Time and Duration will be displayed for the remote
module.
I
MPORTANT
Test results/statistics are cleared when changing test or tool
selection. It is highly advised to generate and save the report once
the current test is completed. See Report Generation on page 79 to
generate and save a report file.
