Traffic Generation & Monitoring
Ethernet Test Set 133
Stream Configuration
³
If DS is selected, go to the next field to
enter the hexadecimal code 00 to FF or
go to the field underneath to enter the
binary code.
The possible values are shown as follows:
³
Flow Label (For IPv6 only): Enter the Flow Label value. The
acceptable range is from 0 to 1048575. The default value is 0.
³
Source/Destination UDP Ports: Enter the Source UDP Port. The
accepted range is from 0 to 65535. The default value is 49184. Enter
the Destination UDP Port. The accepted range is from 0 to 65535. The
default value is 7.
Parameter Value Bit
DSCP Codepoints 000000 (CS0), 001000 (CS1), 010000 (CS2),
011000 (CS3), 100000 (CS4), 101000 (CS5),
110000 (CS6), 111000 (CS7), 001010 (AF11),
001100 (AF12), 001110 (AF13), 010010 (AF21),
10100 (AF22), 010110 (AF23), 011010 (AF31),
011100 (AF32), 011110 (AF33), 100010 (AF41),
100100 (AF42), 100110 (AF43), 101110 (EF),
Default: 000000 (CS0)
1-6
ECN 00 (Not-ECT), 01 (ECT-1), 10 (ECT 0),11 (CE)
Default: 00 (Not-ECT) 7-8
