Ethernet Test Set 11
4 Using the Smart User Interface
Keypad
Refer to the AXS-200 User Guide for more information on how to use the
keypad. The naming convention and purpose for each key is described in
the AXS-200 User Guide.
Power: Turns the unit on and off or puts it into suspend/resume mode.
Start/Stop: Starts and stops the test/tool.
Home: Brings the screen back to the Home menu.
Select: Selects the highlighted item on the screen. Also used to edit and to close a
field.
Back: Returns to the previous screen or menu. In edition mode, it cancels the
data-entry.
Help: Opens and closes the help for the current window.
Brightness: Controls lighting level of screen.
Function Keys: Located under the screen, the three function keys F1, F2, F3 are
used to select the tabs on the screen positioned directly above each key (for
example, F1 is used to select the left-most tab).
Function Arrows: Displays the previous or next set of tabs.
Navigation Arrows: Used to navigate and highlight items within a window. The
up and down arrow keys can be used in edition mode to increase or decrease the
number value.
Alpha-numeric Keypad: Used to perform the following:
³
Enter numbers and letters onto the screen in the same manner as a phone
keypad (for example, for the letter “B”, press the number “2” button two
times).
³
Select menu items by pressing the corresponding numbers.
