System
Ethernet Test Set 215
VNC
To enable VNC and connect from a computer:
1. Press ,
select System, Utilities, and the VNC page.
2. Select VNC Server and select
Enable.
3. Take note of the module’s IP
address displayed on the top of the
screen.
4. Launch the VNC Viewer from the
computer (included in the
AXS-200/850 Ethernet Test Set CD).
5. Enter the IP address of the module into the VNC Viewer window. The
window from the remote module will appear on the computer.
To control the AXS-200/850 Ethernet Test Set remotely from the VNC
Viewer, use the following keys on the computer keyboard (they are
mapped directly to the AXS-200/850 Ethernet Test Set keypad).
Computer Keyboard
AXS-200/850 Ethernet Test Set
Keypad a
F1 Help
F2 Start/Stop Test
F3 Brightness
F4 Left Function Arrow
F5 F1 Function Key
F6 F2 Function Key
F7 F3 Function Key
F8 Right Function Arrow
