Tools
194 AXS-200/850
Trace Route Results
³
No.: Indicates the attempt number.
³
Status: Indicates the status of the attempt.
Status Description
Successful Valid ICMP echo reply received.
Aborted When a user has manually stopped the Trace
Route function before the end of attempts.
Time Out When an ICMP echo reply was not received
within the defined timeout.
Dest. Invalid Specified IP address is reserved for IPv4 and
IPv6.
Hop Reached When a Time Exceeded message is received
from a host while executing the Trace Route
function.
Unreachable When the IP address is unreachable (no
default gateway for an IP address, not in the
same subnet, or the MAC address is
unresolved).
Data Corrupted Parameter problem message is received or
data corruption is found.
Discarded Congestion has been detected and the
request cannot be transmitted. It is only
applicable for the IPv4 version.
Packet Too Big Packet Too Big message is received in
response to a packet that the router cannot
forward because the packet is larger than the
MTU of the outgoing link. It is only applicable
for the IPv6 version.
Undefined For any other errors in Trace Route that do
not fall into one of the above description.
