RFC 2544

64

AXS-200/850

Stream Configuration

³

TOS/DS for IPv4 and Traffic Class (TOS/DS) for IPv6

Select Type of Service (TOS) or Differentiated Services (DS).

Note: It is possible to configure the TOS/DS parameter using either the

hexadecimal code (00 to FF) or TOS/DS using binary code.

³

If TOS is selected, go to the next field to
enter the hexadecimal code 00 to FF or go
to the field underneath to enter the binary
code.

The possible values are shown as follows:

Parameter

Value

Precedence

000 (Routine), 001 (Priority), 010 (Immediate),

011 (Flash), 100 (Flash Override),

101 (CRITIC/ECP), 110 (Internet Control),

111 (Network Control)
Default: 000 (Routine)

Delay

Normal / Low (0/1)
Default: Normal

Throughput

Normal / High (0/1)
Default: Normal

Reliability

Normal / High (0/1)
Default: Normal

Monetary Cost

Normal / Low (0/1)
Default: Normal

Reserved bit

0 or 1
Default: 0
