RFC 2544
60 AXS-200/850
Global Configuration
If User Defined is selected, the following frame sizes are available for
IPv6 version:
If User Defined is selected, use Up or Down arrow, or button to
traverse the fields and enter the Frame Size. Press the Apply Changes
button to apply changes.
³
Throughput: Enable or disable Throughput subtest.
³
Back-to-Back: Enable or disable Back-to-Back subtest.
³
Frame Loss: Enable or disable Frame Loss subtest.
³
Latency: Enable or disable Latency subtest.
Note: All subtests are enabled by default.
³
Pass/Fail Verdict: Enable or disable the Pass/Fail Verdict. Choices are
Enabled and Disabled. The default setting is Enabled. If enabled, the
Pass/Fail Verdict displays the Pass/Fail verdict on the result pages.
Frame Type VLAN Configuration Frame size (Bytes)
User Defined No VLAN 70 to 9600
One VLAN 74 to 9600
Two VLAN 78 to 9600
