Configuring and Starting a Test or Tool
30 AXS-200/850
Configuring a Traffic Generation & Monitoring Test
To configure the Traffic Generation & Monitoring Test
(Background Streams Config):
1. Press ,
select Traffic Generation & Monitoring, Background
Stream Config, and the Transmit tab.
2. Configure the transmit settings by referring to Transmit Configuration
on page 140.
3. Select the Stream tab and configure the stream settings by referring to
Stream Configuration on page 142.
4. Select the Network tab and configure the network settings by referring
to Network Configuration on page 147.
5. Select the VLAN tab and configure the VLAN settings by referring to
VLAN Configuration on page 153.
